Contr
ol elements
9.1
On/Off button
The on/off button have several functions:
Keystroke
Function
5seconds
T
urn on/T
ur
n off
2seconds
Show measuring values
Repeated pushing for 2seconds
T
urn over measuring value display
Fig. 9.1:
On/Off button
10
Display
Laser power in W
att
Absorber temperature
Battery capacity
Status message
Bluetooth connection
active/inactive
Fig. 10.1:
Display
15
17
