11.5 Measurement with pulsed lasers
Limited measurement with pulsed lasers is possible. When it comes to pulsed laser
radiation a correct exposure time measurement up to a pulse frequency of 1kHz and a
duty cycle of 50% is possible.
In case of on/off times shorter than 500μs a correct exposure time measurement is not
possible.
11.6 Reading off measuring values
The last 14 measuring values can be read off from the display of The Cube. You can
read off the last 30measuring values with the optional Android™ PRIMES Cube App for
mobile devices or optional LaserDiagnosticsSoftware LDS.
X Press the on/off button for approx.
2seconds.
The measured values and the time are
displayed.
X Press the on/off button again for 2se-
conds to have the remaining measuring
values (no.8-14) displayed.
