Pro-Form 225 CSX User Manual

13
32
60
14
14. Identify the Right Pedal (60).
Using an adjustable wrench, firmly tighten the
Right Pedal (60) clockwise into the Right Crank
Arm (59).
Firmly tighten the Left Pedal (32)
counterclockwise into the Left Crank Arm
(not shown). IMPORTANT: You must turn the
Left Pedal counterclockwise to attach it.
Adjust the strap on the Right Pedal (60) to the
desired position, and press the ends of the strap
(I) onto the tabs (J) on the Right Pedal. Adjust
the strap on the Left Pedal (not shown) in the
same way.
J
I
59
7
8
1
13. Attach the Tablet Holder (1) to the Console (7)
with four #8 x 5/8" Screws (8); start all the
Screws, and then tighten them.
13

Pro-Form 225 CSX Specifications

General

Brand	Pro-Form
Model	225 CSX
Category	Exercise Bike
Language	English
