PART LIST—Model No. PETL39070 R0498A
Key No. Qty. Description
1 1 Upright/Base
2 2 Motor Pivot Bushing
3 2 Storage Latch Spring
4 1 Storage Latch
5 1 Storage Latch Bracket
6 1 Key/Clip
7 2 3/8 Flatwasher
8 1 Console Base
9* 1 Console
10 1 Speed Potentiometer
11 1 Speed Control
12 1 Battery Cover
13 1 Latch Decal
14 1 Right Foot Rail
15 4 Wire Clip
16 1 Adhesive Clip
17 24 Console Base Screw/Latch Screw
18 30 Small Screw
19 1 Wire Harness
20 8 Platform Screw
21* 1 Motor/Pulley/Flywheel/Fan
22 1 Motor Tension Star Washer
23 3 Upright Washer/Nylon Washer
24 2 Incline Leg Bolt
25 1 Motor Belt
26 7 Nut
27 1 Pulley/Flywheel/Fan
28 1 Motor
29 1 Motor Pivot Bolt
30 8 Isolator
31 1 Left Front Roller Cover
32 1 Front Roller/Pulley
33 1 Right Front Roller Cover
34 1 Electronics Bracket
35 1 Controller
36 1 Choke
37 1 Rear Roller
38 1 Motor Tension Bolt
39 1 Front Roller Adj. Bolt
40 1 Adjustment Washer
41 4 Hood Anchor
42 1 Receptacle
43 1 Motor Pivot Nut
44 1 Receptacle Bracket
45 2 Upright Spacer
46 1 Circuit Breaker
47 29 Small Screw
48 1 Belly Pan
49 2 Upright Pivot Bolt
50 8 Upright Screw
51 2 Handrail
52 2 Base Wheel
53 2 Base Wheel Bolt
54 1 Strain Relief
55 1 Console Wire Harness
56 2 Belt Guide
57 1 Belly Pan Connector
58 1 Frame Belly Pan
59 1 Motor Tension Nut
60 1 Walking Platform
61 1 Walking Belt
62 1 Allen Wrench
Key No. Qty. Description
63 2 Belt Tension Nut
64 1 Belly Pan Plug
65 1 Motor Tension Washer
66 1 Frame
67 2 Ratchet Screw
68 2 Frame Guide
69 1 Incline Leg Bolt
70 2 Cable Tie Clamp
71 1 Latch Spring
72 1 Incline Leg Spacer (short)
73 1 Incline Latch
74 1 Incline Leg Plate
75 1 Incline Leg
76 2 Incline Leg Wheel Bolt
77 2 Incline Leg Wheel
78 2 Incline Wheel Nut
79 1 4” Cable Tie
80 4 Cover Clip
81 1 Ground Wire
82 28 Washer
83 2 Incline Leg Spacer (long)
84 2 Rear Endcap Screw
85 2 Adjustment Bolt
86 1 Rear Roller Cover
87 1 Motor Sleeve
88 2 7.5” Cable Tie
89 1 Magnet
90 1 Releasable Wire Tie
91 1 Shock
92 1 Ratchet Spring Screw
93 4 Frame Guide Spacer
94 1 Ground Wire Screw
95 2 Leg
96 2 Leg Cap
97 5 Leg Pad
98 3 8” Wire Tie
99 1 12” Wire Tie
100 1 Reed Switch Wire
101 1 Left Foot Rail
102 1 Reed Switch Clamp
103 4 Receptacle Bracket Screw
104 1 Ground Wire Washer
105 4 Plastic Stand-Off
106 1 Circuit Board Filter
107 1 Filter
108 1 Filter Bracket
109 1 Ground Wire Nut
110 1 Cable Clamp
# 1 12” Black Wire
# 1 8” Black Wire, Male/Female
# 1 8” Black Wire, Female/Female
# 1 4” Black Wire, Male/Female
# 1 4” Black Wire, Female/Female
# 1 14” White Wire, Female/Female
# 1 8” White Wire, Female/Female
# 1 4” Green Wire, Ring/Female
# 1 User’s Manual
* Includes all parts shown in the box
# These parts are not illustrated
REMOVE THIS EXPLODED DRAWING
AND PART LIST FROM THE MANUAL
Save this EXPLODED DRAWING and PART LIST for future reference.
