Pro-Form 4.0 RT - Attach Handlebars; Attach Rear Upright Cover

12
10
10. Identify the Rear Upright Cover (57) and orient it
as shown.
Attach the Rear Upright Cover (57) to the Upright
(2) with an M4 x 16mm Screw (77).
77
57
2
9
9. Identify the Right Handlebar (20) and orient it as
shown.
Attach the Right Handlebar (20) to the Upright
(2) with two M8 x 16mm Screws (69).
Attach the Left Handlebar (7) in the same
way.
7
20
2
69
69
