Pro-Form 4.0 RT - Attach Rear Stabilizer; Attach Seat Handlebar

9
4
4. Orient the Seat Handlebar (10) as shown.
Attach the Seat Handlebar (10) to the Seat
Carriage (41) with four M8 x 38mm Screws (67).
Plug the Seat Handlebar Wire (A) into the
Receptacle (42) in the right side of the exercise
bike.
10
67
41
A
42
3. While a second person lifts the rear of the Frame
(1), attach the Rear Stabilizer (16) to the Frame
with two M10 x 105mm Screws (65).
16
65
1
3
