9
8
58
10
7
8. Slide the Console (58) onto the Console
Bracket (10) on the Handlebar (7).
7. The Console (58) can use two AAA batteries (not
included); alkaline batteries are recommended.
Do not use old and new batteries together or
alkaline, standard, and rechargeable batter-
ies together. IMPORTANT: If the Console has
been exposed to cold temperatures, allow
it to warm to room temperature before you
insert batteries. Otherwise, you may damage
the console displays or other electronic com-
ponents. Remove the battery cover, and insert
the batteries into the battery compartment (B).
Make sure to orient the batteries as shown by
the diagram inside the battery compartment.
Then, reattach the battery cover.
7
58
B
To Next Page
