12
11
11. Attach the Seat Handlebar (18) to the Seat
Carriage (11) with four M8 x 40mm Screws (56);
start all the Screws, and then tighten them.
56
18
11
12
12. Slide the Backrest Frame (14) onto the Seat
Handlebar (18).
Attach the Backrest Frame (14) with four M6 x
30mm Screws (51) and four M6 Washers (112);
start all the Screws, and then tighten them.
18
14
51
112
To Next Page
