8
9. Identify the Left Upper Body Arm (56) (refer to the draw-
ing on page 4). Hold the Left Upper Body Arm near the
Left Upright (14) as shown. Make sure that the
Resistance Knob (64) is on the indicated side. Attach the
Left Upper Body
Arm to the Left Upright with two 3” Bolts
(7), two Washers (40), and two 3/8” Star Washers (54) as
shown.
Attach the Right Upper Body Arm (59) to the Right
Upright (15) as described above. Be careful not to
pinch the wires in the Right Handrail (109).
Lift the treadmill frame (see HOW TO FOLD THE
TREADMILL FOR STORAGE on page 12). Make sure
that the frame is centered between the two Handrails
(4).
Firmly tighten all of the bolts and screws used in
steps 3 and 4. Then, lower the frame to the floor.
15
14
4
109
56
64
59
9
40
54
7
7
54
10.Make sure that all parts used in assembly are properly tightened before you use the treadmill. Keep
the included allen wrenches in a secure place for adjustment purposes (see page 14).
To protect the floor or
carpet, place a mat under the treadmill.
40
