Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the user’s manual for information about ordering replacement parts.
Key No. Qty. Description Key No. Qty. Description
Part List—Model No. PFEVBE33330
R0503A
1 2 Upright
2 1 Crossbar
3 1 Front Leg
4 1 Foot Plate
5 1 Bench Frame
6 8 M10 Washer
7 1 Leg Lever
8 1 Curl Frame
9 1 Curl Pad
10 4 25mm Square Inner Cap
11 11 M10 Nylon Locknut
12 1 Backrest
13 1 M10 x 65mm Adjustment Knob
14 1 Left Backrest Frame
15 1 Right Backrest Frame
16 2 25mm x 50mm Inner Cap
17 1 Seat
18 2 76mm Round Inner Cap
19 2 Weight Rest
20 4 Weight Rest Insert
21 2 Large Adjustment Knob
22 6 Leg Pad
23 8 M10 x 80mm Bolt
24 4 50mm x 70mm Inner Cap
25 2 50mm Round Inner Cap
26 6 M6 x 16mm Bolt
27 1 Locking Pin
28 1 M10 x 180mm Bolt
29 1 M10 x 70mm Adjustment Knob
30 1 Plastic Bushing
31 1 Ring Pin
32 1 Long Pad Tube
33 6 19mm Round Inner Cap
34 2 Short Pad Tube
35 1 25mm Angle Cap
36 1 25mm Round Inner Cap
37 4 M6 x 38mm Bolt
38 4 M6 Washer
39 1 Right Barbell Hook
40 1 Left Barbell Hook
41 1 Weight Tube Adaptor
42 1 Spring Clip
43 2 Spring Clip Cover
# 1 Grease Packet
# 1 User’s Manual
# 1 Exercise Guide
REMOVE THIS PART LIST/EXPLODED DRAWING
FROM THE MANUAL
SAVE THIS PART LIST/EXPLODED DRAWING AND THE USER’S MANUAL
FOR FUTURE REFERENCE
