10
90
6
87
86
89
81
11
28
11
28
A
6. Hold the Right Handrail (87) near the Right
Upright (90). Insert the Upright Wire (81) through
the hole in the bottom of the Right Handrail as
shown, and then remove the wire tie (A) from the
Upright Wire.
Next, attach the Right Handrail (87) to the Right
Upright (90) with two 5/16" x 2 1/2" Screws (28)
and two 5/16" Star Washers (11). Make sure not
to pinch the Upright Wire (81). Firmly tighten
the Screws.
Then, attach the Left Handrail (86) to the Left
Upright (89) in the same way. Note: There are
no wires on the left side.
7. If there are four screws (E) in the locations
shown, remove and discard them.
7
E
E
To Next Page
