14
1 1 Frame
2 1 Front Stabilizer
3 1 Frame Rail
4 1 Seat Carriage
5 1 Rear Stabilizer
6 1 Seat Frame
7 4 Stabilizer Endcap
8 2 Seat Carriage Bushing
9 1 Backrest
10 1 Seat
11 1 Upright
12 1 Console
13 1 Flywheel
14 1 Crank/Pulley
15 1 Left Side Shield
16 1 Right Side Shield
17 1 Side Shield Cover
18 1 Belt
19 1 "C" Magnet
20 1 Left Pedal
21 2 Pedal Strap
22 1 Right Pedal
23 1 Hook
24 2 Foam Grip
25 1 Seat Carriage Endcap
26 1 Seat Knob
27 1 Frame Rail Endcap
28 1 "C" Magnet Bracket
29 1 Crank Bearing Assembly
30 1 M6 x 53mm Screw
31 1 Return Spring
32 1 Lower Cable
33 4 M6 Nut
34 1 Flywheel Axle
35 2 Flywheel Bearing
36 2 Flywheel Washer
37 7 M6 x 16mm Screw
38 1 M6 Flat Washer
39 5 M4 x 25mm Screw
40 10 M4 x 16mm Screw
41 8 M5 x 6mm Screw
42 2 M10 x 52mm Button Bolt
43 8 M10 Split Washer
44 6 M10 Nylon Locknut
45 1 Reed Switch Clamp
46 1 Reed Switch/Wire
47 4 M10 x 66mm Button Bolt
48 2 M10 x 75mm Carriage Bolt
49 2 M10 x 80mm Button Bolt
50 1 M6 x 25mm Bolt
51 1 "U" Bracket
52 2 M6 Eyebolt
53 2 M6 Nylon Locknut
54 3 M8 Nylon Locknut
55 1 M6 Large Washer
56 1 Seat Endcap
57 2 M4 x 12mm Screw
58 1 Magnet
59 1 Cable Clamp
# 1 User's Manual
# 1 Allen Wrench
Note: “#” indicates a non-illustrated part.
Specifications are subject to change without
notice. See the back cover of this manual for infor-
mation about ordering replacement parts.
EXPLODED DRAWING—Model No. 831.283170 R0802A
Key No. Qty. Description Key No. Qty. Description Key No. Qty. Description
To Next Page
