11
11. Identify the Right Pedal (21), which is marked
with an “R.” Using an adjustable wrench, firmly
tighten the Right Pedal clockwise into the Right
C
rank (23). Tighten the Left Pedal (not shown)
counterclockwise into the Left Crank (not
s
hown). IMPORTANT: Tighten both Pedals as
firmly as possible. After using the exercise
cycle for one week, retighten the Pedals.
To loosen the strap on the Right Pedal (21),
press the indicated tab and pull the strap
upward. To tighten the strap, simply pull the end
of the strap downward. Adjust the strap on the
Left Pedal (not shown) in the same way.
11
12. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly
is completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
2
1
23
Strap
Tab
To Next Page
