System Description
Machine Specifications
Utilities
• 110 / 1ph / 60hz / 10 Amp Service
Standard Speed
• Variable to 9 Rpm
Drive
• Self-adjusting Heavy Duty Chain Drive
• Soft Start Rotation for Unstable Loads
Control Features
• User Friendly Interface
• Home Position Alignment Stops the Table at the Same Location Each Cycle
• Variable Speed Film Carriage Up/ Down Control
• Adjustable Top and Bottom Wrap Count (1-9)
• Film Carriage Manual Jog Functionality
• Photocell For Automatic Load Height Detection
• Table Jogging
• Password Protected Advanced Settings
Film Delivery
• Powered Pre-stretch Film Carriage
• 200 % Film Prestretch
• 20" Film Width Capacity up to 95 Gauge Film Thickness
• High Strength Chain Lift
• Variable Frequency Drive Motor
Structural Features
• Machine Weight- 1,650 lbs.
• Wraps Loads 52”x52”x80” High up to 4,000 lbs.
• Structural Steel Construction Throughout
• Easy Access To All Components
• Limited Proprietary Parts For Ease Of Maintenance
