Tower
Tower
PartRef Description Part# Quantity
1 TowerCover 1
2 Tower 1
3 FrameSettingPlate 1
4 CarriageLiftChainAdjustScrew 738981 4
5 TowerMotor 734350 1
TowerGearbox 744999 1
TowerLiftKit(Motor,Gearbox,Shaft) 1011889
6 CarriageLiftMotorShaft 736968 1
7 TransitionFrame 748439 1
8 LiftingFrame 748440 1
9 TowerFrame 1
10 DrivenShaftFixingBuckle 748441 1
11 CarriageLiftDrivenShaft 738980 1
12 CarriageLiftDrivenSprocket 738979 2
13 CarriageLiftChain(8'Tower) 0364241NO 2
CarriageLiftChain(9'Tower) 0364242NO 2
14 SlipTrack 1
15 SlipBlock 738982 4
16 Bearing 739980 2
17 MotorSprocket 738978 2
18 LowerBottomGuardPanel 739553 1
19 MiddleSideGuardPanel 739554 1
