PRESSURE MANIFOLD
BLAZER 980073 08/21/03
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000210 SCR, 1/4-20 X 3/4 SOCHD
2 87162 WASHER, 1/4 SPLIT LOCK
3 10-805311 HOSE, 3/16X10.5 (1/4FT BS)
4 10-805372 HOSE, 3/16 X 21-3/4
5 10-805426 HOSE, 3/16X12 (1/4FT BS)
6 56015 NIPPLE, 1/4 HEX
7 11-800069 PLUG, 1/2 SOCHD BR
8 11-800090 CONN, 3/8FP X 1/4P BR
9 11-800128 NIP, HEX 1/4 SST
10 11-800362 TEE, SERVICE 3/8
11 11-800429 ADAPTER, 3/8MPT X 1/2 FPT SST
12 12-800040 ELL, 1/8P X 1/4T BR
13 12-800060 CONN, 1/4P X 1/4T BR
14 12-800065 CONN, 1/8P X 1/4T
15 12-800282 CONN, 3/8P X 1/2T BR
16 12-800345 FTTG, BRB 3/8P X 5/8H BR
17 22015 COUPLER, 1/4 QD
18 15-808081 REG, PRES W/O INNER SPRING
19 15-808131 ASSY, CHECK VALVE MANIFOLD
20 790106 ACCUMULATOR, 250PSI CAT 6026
21 52-501761 MANIFOLD, PRESSURE REG
22 14-806549 SCREEN, CHECK VALVE
23 15-808094 VALVE, CHECK
24 43-810053 O-RING, .676ID X .816OD
25 03-000246 CLAMP, HOSE #8 SST
26 09-805330 HOSE, WTR 5/8 X 53”
27 10-805423 HOSE, HP 3/8 X 10-1/2
28 10-805361 HOSE, HP 3/8 X 14-1/2
29 10-805424 HOSE, HP 3/8 X 55”
