EXHAUST HEAT EXCHANGER
BLAZER 980073 09/16/02
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000078 SCR, 1/4-20 X 1” HXHD GRD8
2 00-000315 SCR, CAP 5/16-18 X 7/8 SOCHD
3 57031 NUT, 5/16-18 HEX
4 87162 WASHER, 1/4 SPLIT LOCK
5 87083 WASHER, 5/16 SPLIT LOCK PLTD
6 02-000066 FLATWASHER, 1/4
7 03-000086 CLAMP, MFLR 1-1/4
8 03-000248 CLMP, HOSE #16 1-1/2 MIN 1-3/4
9 10-805423 HOSE, HP 3/8 X 10-1/2”
10 10-805424 HOSE, HP 3/8 X 55” W/HEAT BARRIER
11 11-800276 ELL, 3/8 BR
12 11-800392 NIP, 3/8P X 12/T SST
13 12-800282 CONN, 3/8P X 1/2T BR
14 12-800347 ELL, 3/8P X 1/2T 45 DEG. BR
15 35-900050 SENS. TEMP 240 DEG
16 35-900170 SENS. TEMP 275 DEG
17 42-902212 ONAN GSKT, EXH#154-2747
18 52-501998 TEE, SOL. OUTL 3/8 BR
19 55-501801 TB, EXH HE
20 57-520093 HEAT EXCHANGE, EXH
21 70015 SCR, 1/4-20 X 3/4 HHCS SS
22 57006 NUT, 1/4-20 HEX
23 02-000044 LKWSR, 1/4 SST
24 43-807086 GSTKT, EXH FLG
25 52-501654 NUT, ADAPT BUSH
26 57-820094 ASSY, COIL MT & CASING
27 58-500791 CASTING, CAT CONV W/TB
