Procon A1M - Page 37

35
Holding Register (Analogue Output) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Current Hour 48 40049 0 … 23
9
(9)
#18
9
(9)
#18
9 9
(9)
#18
Current Minute 49 40050 0 … 59
9
(9)
#18
9
(9)
#18
9 9
(9)
#18
Outdoor Temperature By BMS
(signed)
50 40051
Temperature value in ºC multiplied by 10.
0xFE70 = -40ºC … 0x036B = 87.5ºC
9
#9
9
#9
9
#9
Outdoor Temperature By BMS 51 40052
Temperature value in ºC multiplied by 10.
0x0000 = 0.0ºC ... 0x036B = 87.5ºC.
9
#10
9
#10
9
#10
Setting Water Temperature
(signed)
52 40053
Temperature value in ºC multiplied by 100.
(see note *)
9
#11
9
#12
9
#15
9
#16
Setting Water Temperature 53 40054
Temperature value in ºC multiplied by 100.
(see note **)
9
#11
9
#12
9
#15
9
#16
Thermostat Target Temperature
– Zone 1 (signed)
54 40055
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Thermostat Target Temperature
– Zone 1
55 40056
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Thermostat Target Temperature
– Zone 2 (signed)
56 40057
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Thermostat Target Temperature
– Zone 2
57 40058
Temperature value in ºC multiplied by 100.
(see note **)
9 9
HC Control Type 58 40059
0 = Heating
1 = Cooling
9 9
Own Refrigerant Address
[READ ONLY]
66 40067 0 … 32
9 9 9 9 9 9 9 9 9
Defrost
[READ ONLY]
67 40068
0 = Normal
1 = Standby
2 = Defrost
3 = Waiting Restart
9 9 9 9 9 9 9
Residual Heat Removal
[READ ONLY]
68 40069
0 = Normal
1 = Prepared
2 = Residual Heat Removal
9 9
