Procon A1M - Page 41

39
Holding Register (Analogue Output) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Return Temperature
[READ ONLY]
104 40105
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Water Inlet Temperature
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note **)
9 9
9 9 9 9 9
Tank Water Temperature
(signed)
[READ ONLY]
105 40106
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Tank Water Temperature
[READ ONLY]
106 40107
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Flow Temperature – Zone 1
(signed)
[READ ONLY]
107 40108
Temperature value in ºC multiplied by 100.
(see note *)
9 9
External Water Temperature 1
(signed)
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note *)
9 9
9 9
Flow Temperature – Zone 1
[READ ONLY]
108 40109
Temperature value in ºC multiplied by 100.
(see note **)
9 9
External Water Temperature 1
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note **)
9 9
9 9
Return Temperature – Zone 1
(signed)
[READ ONLY]
109 40110
Temperature value in ºC multiplied by 100.
(see note *)
9 9
External Water Temperature 3
(signed)
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note *)
9
Return Temperature – Zone 1
[READ ONLY]
110 40111
Temperature value in ºC multiplied by 100.
(see note **)
9 9
External Water Temperature 3
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note **)
9
Flow Temperature – Zone 2
(signed)
[READ ONLY]
111 40112
Temperature value in ºC multiplied by 100.
(see note *)
9 9
External Water Temperature 2
(signed)
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note *)
9 9
