Holding Register (Analogue Output) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Room Temperature – Zone 1
(signed)
[READ ONLY]
93 40094
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Room Temperature – Zone 1
[READ ONLY]
94 40095
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Room Temperature – Zone 2
(signed)
[READ ONLY]
95 40096
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Room Temperature – Zone 2
[READ ONLY]
96 40097
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Refrigerant Liquid Temperature
(signed)
[READ ONLY]
97 40098
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Refrigerant Liquid Temperature
[READ ONLY]
98 40099
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Outdoor Ambient Temperature
(signed)
[READ ONLY]
99 40100
Temperature value in ºC multiplied by 10.
0xFE70 = -40.0ºC … 0x036B = 87.5ºC
9 9 9 9 9 9 9 9
Outdoor Ambient Temperature
[READ ONLY]
100 40101
Temperature value in ºC multiplied by 10.
0x0000 = 0.0ºC ... 0x036B = 87.5ºC.
9 9 9 9 9 9 9 9
Flow Temperature (signed)
[READ ONLY]
101 40102
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Water Outlet Temperature
(signed)
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note *)
9 9
9 9 9 9 9
Flow Temperature
[READ ONLY]
102 40103
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Water Outlet Temperature
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note **)
9 9
9 9 9 9 9
Return Temperature (signed)
[READ ONLY]
103 40104
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Water Inlet Temperature (signed)
[READ ONLY]
Temperature value in ºC multiplied by 100.
(see note *)
9 9
9 9 9 9 9
