Procon A1M - Page 39

37
Holding Register (Analogue Output) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Heat Source Status
[READ ONLY]
80 40081
0 = H/P
1 = IH
2 = BH
3 = IH + BH
4 = Boiler
9 9
Temperature Setpoint – Zone 1
(signed)
[READ ONLY]
81 40082
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Temperature Setpoint – Zone 1
[READ ONLY]
82 40083
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Temperature Setpoint – Zone 2
(signed)
[READ ONLY]
83 40084
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Temperature Setpoint – Zone 2
[READ ONLY]
84 40085
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Flow Temperature Setpoint –
Zone 1 (signed)
[READ ONLY]
85 40086
Temperature value in ºC multiplied by 100.
(see note *)
9 9 9 9 9 9 9 9
Flow Temperature Setpoint –
Zone 1
[READ ONLY]
86 40087
Temperature value in ºC multiplied by 100.
(see note **)
9 9 9 9 9 9 9 9
Flow Temperature Setpoint –
Zone 2 (signed)
[READ ONLY]
87 40088
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Flow Temperature Setpoint –
Zone 2
[READ ONLY]
88 40089
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Legionella Temperature Setpoint
(signed)
[READ ONLY]
89 40090
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Legionella Temperature Setpoint
[READ ONLY]
90 40091
Temperature value in ºC multiplied by 100.
(see note **)
9 9
DHW Temperature Drop (signed)
[READ ONLY]
91 40092
Temperature value in ºC multiplied by 10.
0xFF38 = -20.0ºC … 0x0433 = 107.5ºC
9 9
DHW Temperature Drop
[READ ONLY]
92 40093
Temperature value in ºC multiplied by 10.
0x0000 = 0ºC … 0x0433 = 107.5ºC
0 = 0.0ºC … 1075 = 107.5ºC
9 9
