Procon A1M - Page 59

57
Input Register (Analogue Input) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Temperature Setpoint – Zone 1
(signed)
40 30041
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Temperature Setpoint – Zone 1 41 30042
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Temperature Setpoint – Zone 2
(signed)
42 30043
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Temperature Setpoint – Zone 2 43 30044
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Flow Temperature Setpoint –
Zone 1 (signed)
44 30045
Temperature value in ºC multiplied by 100.
(see note *)
9 9 9 9 9 9 9 9
Flow Temperature Setpoint –
Zone 1
45 30046
Temperature value in ºC multiplied by 100.
(see note **)
9 9 9 9 9 9 9 9
Flow Temperature Setpoint –
Zone 2 (signed)
46 30047
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Flow Temperature Setpoint –
Zone 2
47 30048
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Legionella Temperature Setpoint
(signed)
48 30049
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Legionella Temperature Setpoint 49 30050
Temperature value in ºC multiplied by 100.
(see note **)
9 9
DHW Temperature Drop (signed) 50 30051
Temperature value in ºC multiplied by 10.
0xFF38 = -20.0ºC … 0x0433 = 107.5ºC
9 9
DHW Temperature Drop 51 30052
Temperature value in ºC multiplied by 10.
0x0000 = 0ºC … 0x0433 = 107.5ºC
0 = 0.0ºC … 1075 = 107.5ºC
9 9
Room Temperature – Zone 1
(signed)
52 30053
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Room Temperature – Zone 1 53 30054
Temperature value in ºC multiplied by 100.
(see note **)
9 9
