Input Register (Analogue Input) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Room Temperature – Zone 2
(signed)
54 30055
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Room Temperature – Zone 2 55 30056
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Refrigerant Liquid Temperature
(signed)
56 30057
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Refrigerant Liquid Temperature 57 30058
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Outdoor Ambient Temperature
(signed)
58 30059
Temperature value in ºC multiplied by 10.
0xFE70 = -40.0ºC … 0x036B = 87.5ºC
9 9 9 9 9 9 9 9
Outdoor Ambient Temperature 59 30060
Temperature value in ºC multiplied by 10.
0x0000 = 0.0ºC ... 0x036B = 87.5ºC.
9 9 9 9 9 9 9 9
Flow Temperature (signed)
60 30061
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Water Outlet Temperature
(signed)
Temperature value in ºC multiplied by 100.
(see note *)
9 9 9 9
9 9 9
Flow Temperature
61 30062
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Water Outlet Temperature
Temperature value in ºC multiplied by 100.
(see note **)
9 9 9 9
9 9 9
Return Temperature (signed)
62 30063
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Water Inlet Temperature (signed)
Temperature value in ºC multiplied by 100.
(see note *)
9 9 9 9
9 9 9
Return Temperature
63 30064
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Water Inlet Temperature
Temperature value in ºC multiplied by 100.
(see note **)
9 9 9 9
9 9 9
Tank Water Temperature
(signed)
64 30065
Temperature value in ºC multiplied by 100.
(see note *)
9 9
