Input Register (Analogue Input) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Refrigerant 5 Error Code Digit 1 96 30097 (see note ^)
9 9
Refrigerant 5 Error Code Digit 2 97 30098 (see note ^^)
9 9
Refrigerant 6 Error Code Digit 1 98 30099 (see note ^)
9 9
Refrigerant 6 Error Code Digit 2 99 30100 (see note ^^)
9 9
Heat Pump Frequency – Slave 7 100 30101
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave 8 101 30102
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave 9 102 30103
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave
10
103 30104
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave
11
104 30105
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave
12
105 30106
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave
13
106 30107
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave
14
107 30108
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Heat Pump Frequency – Slave
15
108 30109
Frequency value in Hz
0 = 0Hz … 255 = 255Hz
9 9
9
Evaporating Temperature
(signed)
109 30110
Temperature value in ºC multiplied by 100.
(see note *)
9 9 9 9
9 9 9
Evaporating Temperature 110 30111
Temperature value in ºC multiplied by 100.
(see note **)
9 9 9 9
9 9 9
