Input Register (Analogue Input) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Water Pump 1 – PWM Duty 141 30142
Duty value in %
0 = 0% … 100 = 100%
9
Water Pump 1 – PWM Duty
Feedback
142 30143
Duty value in %
0 = 0% … 100 = 100%
3-Way Valve 1 143 30144
0 = OFF (stop)
1 = ON (run)
9
9
H/C Control Type 144 30145
0 = Heating
1 = Cooling
9 9
MRC Prohibit 145 30146
Bit packed value:
Bit 0 – System On/Off (0 = ON, 1 = Prohibit)
Bit 1 – Running Mode (0 = ON, 1 = Prohibit)
Bit 2 – Setting Temp (0 = ON, 1 = Prohibit)
Bit 3 – Undefined (always 0)
Bit 4 – Function Setting (0 = Normal, 1 = Function
Setting)
Bits 5, 6 and 7 – Undefined (always 0)
9 9 9 9
Version of Protocol (upper) 146 30147
Version of Protocol is a value in BCD
e.g. V3.01 = 3 (upper) and 1 (lower)
9 9 9 9 9 9 9
Version of Protocol (lower) 147 30148
Version of Protocol is a value in BCD
e.g. V3.01 = 3 (upper) and 1 (lower)
9 9 9 9 9 9 9
Version of Model (upper) 148 30149
Version of Model is a value in BCD
e.g. V2.00 = 2 (upper) and 0 (lower)
9 9 9 9 9 9 9
Version of Model (lower) 149 30150
Version of Model is a value in BCD
e.g. V2.00 = 2 (upper) and 0 (lower)
9 9 9 9 9 9 9
Capacity of Supplying Electricity 150 30151
Value in Watts
0 = 0,0 W
…
255 = 25,5 W
9 9 9 9 9 9 9
