Procon A1M - Page 68

66
Input Register (Analogue Input) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Model Profile 1 151 30152
0 = FTC2B
1 = FTC4
2 = FTC5
128 = CAHV1A
129 = CAHV1B
130 = CRHV1A
131 = CRHV1B
132 = EAHV1A
133 = EAHV1B
134 = QAHV1A
135 = QAHV1B
144 = PWFY1
9 9 9 9 9 9 9
Model Profile 2 (refrigerant
address)
152 30153
0 = Address 0
…
255 = Address 255
(addresses 7 – 255 not used for FTC)
9 9 9 9 9 9 9
Energy Consumption Measured
Date – Year
153 30154
Date of last energy consumption measurement –
Year
9
Energy Consumption Measured
Date – Month
154 30155
Date of last energy consumption measurement –
Month
9
Energy Consumption Measured
Date – Day
155 30156
Date of last energy consumption measurement –
Day
9
Last Measured Heating Energy
Consumption – kWh part
156 30157
Last measured heating energy consumption – kWh
part of the value.
0 = 0kWh … 65535 = 65535kWh
9
Last Measured Heating Energy
Consumption – Wh part
157 30158
Last measured heating energy consumption – Wh
part of the value.
0 = 0Wh … 99 = 99Wh
9
Last Measured Cooling Energy
Consumption – kWh part
158 30159
Last measured cooling energy consumption – kWh
part of the value.
0 = 0kWh … 65535 = 65535kWh
9
Last Measured Cooling Energy
Consumption – Wh part
159 30160
Last measured cooling energy consumption – Wh
part of the value.
0 = 0Wh … 99 = 99Wh
9
Last Measured DHW Energy
Consumption – kWh part
160 30161
Last measured DHW energy consumption – kWh
part of the value.
0 = 0kWh … 65535 = 65535kWh
9
