Procon A1M - Page 79

77
Holding Register (Analogue Output) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
Lossnay
LGH Series
Outdoor Temperature (signed)
[READ ONLY]
306 40307
Temperature value in ºC multiplied by 10.
(see note *)
Note: Only available when ‘Outdoor Temperature
Sensor’ value = 1 (Equipped).
9
Outdoor Temperature
[READ ONLY]
307 40308
Temperature value in ºC multiplied by 10.
(see note **)
Note: Only available when ‘Outdoor Temperature
Sensor’ value = 1 (Equipped).
9
Room Temperature A
[READ ONLY]
308 40309
Temperature value in ºC multiplied by 10.
0 = 0ºC … 400 = 40ºC
Note: Only available when ‘Return Air Temperature
Sensor’ value = 1 (Equipped).
9
Room CO2 Level
[READ ONLY]
309 40310
CO2 level divided by 10.
0 = 0ppm … 240 = 2400 and above.
[Value 254 = Under detecting]
[Value 255 = No sensor]
Note: Only available when ‘CO2 Level Sensor’
value = 1 (Equipped).
Fault/Error Code (hex)
[READ ONLY]
310 40311
0x8000 = No error
0x6999 = Bad communication with unit
(Refer to Lossnay unit documentation for
description of other fault code values)
9
Fault/Error Code (decimal)
[READ ONLY]
311 40312
8000 = No error
6999 = Bad communication with unit
(Refer to Lossnay unit documentation for
description of other fault code values)
9
Thermo On/Off
[READ ONLY]
312 40313
0 = Thermo OFF
1 = Thermo ON
Energy Consumption
[READ ONLY]
313 40314
Value in kWh multiplied by 10.
0 = 0kWh … 65535 = 6553.5kWh
9
Actual Operation Mode
[READ ONLY]
314 40315
0 = Not auto mode
1 = Determining
2 = Heating
3 = Cooling
