Access Control Lists (ACLs)
Enable ACL “Deny” Logging
10.38.110.54
10.38.100.127
Syslog Server
Configure extended ACL 143
here to deny Telnet access to
inbound Telnet traffic from IP
address 10.38.100.127.
Block Telnet access to the
network from this host.
Console
2610 Switch
Console RS-232 Port
10
11
Figure 9-31. Example of an ACL Log Application
Figure 9-32. Commands for Applying an ACL with Logging to Figure 9-31
9-69
