Configuring Port-Based and User-Based Access Control (802.1X)
Displaying 802.1X Configuration, Statistics, and Counters
Viewing 802.1X Open VLAN Mode Status
You can examine the switch’s current VLAN status by using the show port-
access authenticator vlan and show port-access authenticator < port-list > com-
mands. Figure 11-12 shows related VLAN data that can help you to see how
the switch is using statically configured VLANs to support 802.1X operation.
ProCurve(config)# show port-access authenticator vlan
Port Access Authenticator VLAN Configuration
Port-access authenticator activated [No] : No
Allow RADIUS-assigned dynamic (GVRP) VLANs [No] : No
Access Unauth Auth
Port Control VLAN ID VLAN ID
---- -------- -------- ------- -
1 Auto 100 101
2 Auto 100 101
3 Auto 100 0
4 Auto 100 101
Figure 11-10. Example Showing Ports Configured for Open VLAN Mode
ProCurve (config)# show port-access authenticator 1-3
Port Access Authenticator Status
Port-access authenticator activated [No] : No
Allow RADIUS-assigned dynamic (GVRP) VLANs [No] : No
Current Current RADIUS ACL
Port Status VLAN ID Port COS Applied?
---- ------ -------- ----------- ---------- -
1 Closed 100 No-override No
2 Open 101 No-override No
Figure 11-11.Example Showing Ports Configured for Open VLAN Mode
Note that because a temporary Open VLAN port assignment to either an
authorized or unauthorized VLAN is an untagged VLAN membership, these
assignments temporarily replace any other untagged VLAN membership that
is statically configured on the port.
11-54
