OB7 Collaborative Robot User Manual Version 0.6
Meet OB7 / 37
MEET OB7
OB7 on Stand OB7 on Stand With Assembly Table
OB7’s 7 joint arm has the capability to reach around objects.
OB7’s 7 Joints
Joint 1
Joint 2
Joint 7
Joint 6
Joint 5Joint 4
Joint 3
OB7 can be used in many dierent congurations: On a stand, on stand with assembly table, and on a
ceiling mount (not pictured).
OB7 has 7 joints which allows maximum exibility.
