PROEL FLASH8A V2 - Flash8 A Regler (Abb.1); Flash8 A Anschlüsse (Abb.2); Flash8 A Pannello DI Controllo (Fig.1); Flash8 A Connessioni (Fig.2)

11
LINE IN (ingresso)
Jack (bilanciato)
LINE IN
Jack (balanced)
sleeve - ground
tip - hot
ring - cold
LINE / MIC IN (ingresso)
XLR bilanciato maschio
LINE / MIC IN
Balanced male XLR
INPUT / LINK ALTOPARLANTI
Connettore per cavo tipo Speakon Neutrik NL4
PROEL code - NL4FX
Codice PROEL - NL4FX
PROEL code - NL4FX
Codice PROEL - NL4FX
SPEAKER POWER INPUT / LINK
Neutrik NL4 Speakon Cable Connector
ground
hot
cold
LINE IN (ingresso)
Jack (sbilanciato)
LINE IN
Jack (unbalanced)
ground
tip - hot
cold
*nota: connettere insieme cold e ground
per cavi da bilanciato a sbilanciato
*note: connect both cold and ground
to make cable from balanced to unbalanced
2-
1+
2+
1-
20mm
0.8"
8mm
0.3"
RED
BLACK
positive / red / rosso
n.c.
1+
negative / black / nero
1-
n.c.
POWER OUTPUT - uscite altoparlanti
Connettore per cavo tipo Speakon Neutrik NL4
SPEAKER POWER OUTPUT
Neutrik NL4 Speakon Cable Connector
2-
1+
2+
1-
channel 1 positive
canale 1 positivo
1+
channel 1 negative
canale 1 negativo
1-
OUTPUT 1
2-
1+
2+
1-
bridge positive
n.c.
1+
bridge negative
1-
n.c.
OUTPUT BRIDGE
2-
1+
2+
1-
20mm
0.8"
8mm
0.3"
RED
BLACK
channel 2 positive
n.c.
1+
channel 2 negative
1-
n.c.
OUTPUT 2
uscita 1 uscita BRIDGE uscita 2
channel 2 negative
canale 2 negativo
NOTE: channels 3 and 4 are equal to channel 1 and 2 respectively.
NOTA: canali 3 e 4 sono equivalenti ai canali 1 e 2 rispettivamente.
2+
channel 2 positive
canale 2 positivo
2-
MIX OUT (uscita)
XLR sbilanciato femmina
MIX OUT (output)
Unbalanced female XLR
ground
hot
FLASH 8A CONTROL PANEL (FIG.1)
FLASH8A REGLER (ABB.1)
FLASH 8A PANNELLO DI CONTROLLO (FIG.1)
FLASH8A PANNEAU DE COMMANDE (FIG.1)
)1FLASH8A
FLASH8A PANEL DE CONTROL (FIG.1)
FLASH 8A CONNECTIONS (FIG.2)
FLASH8A ANSCHLÜSSE (ABB.2)
FLASH 8A CONNESSIONI (FIG.2)
FLASH8A CONNEXIONS (FIG.2)
)2FLASH8A
FLASH8A CONEXIONES (FIG.2)
LINE / MIC IN
Balanced male XLR
LINE / MIC IN (ingresso)
XLR bilanciato maschio
LINE / MIC IN (Eingang)
XLR symmetrisch, männlich
LINE / MIC IN (entrée)
XLR symétrique mâle
LINE / MIC IN (entrada)
XLR balanceado macho
LINE / MIC IN


MIX OUT (output)
Unbalanced female XLR
MIX OUT (uscita)
XLR sbilanciato femmina
MIX OUT (Ausgang)
XLR unsymmetrisch, weiblich
MIX OUT (sore)
XLR asymétrique femelle
MIX OUT (salida)
XLR desbalanceado hembra
MIX OUT (
XLR 
LINE IN
Jack (balanced)
LINE IN (ingresso)
Jack (bilanciato)
LINE IN (Eingang)
Klinkenstecker (symmetrisch)
LINE IN (entrée)
Jack (symétrique)
LINE IN (entrada)
Jack (balanceado)
LINE IN




LINE IN
Jack (unbalanced)
LINE IN (ingresso)
Jack (sbilanciato)
LINE IN (Eingang)
Klinkenstecker (unsymmetrisch)
LINE IN (entrée)
Jack (asymétrique)
LINE IN (entrada)
Jack (debalanceado)
LINE IN

 


*note: connect both cold and ground to make cable from balanced to unbalanced
*nota: conneere insieme cold e ground per cavi da bilanciato a sbilanciato
*Hinweis: bei Verbindung von symmetrisch zu unsymmetrisch Kalt und Masse zusammen anschließen
*remarque : connecter ensemble cold et ground pour des câbles de symétrique à asymétrique
*nota: conecte juntos cold y ground para cables de balanceado a desbalanceado
 


