7
MODEL WX8A WX10A
System type 2-way coaxial vented stage monitor 2-way coaxial vented stage monitor
Low Frequency Device 8” woofer with 2"VC 10” woofer with 2"VC
High Frequency Device 1” compression driver with 1"VC 1” compression driver with 1"VC
Angular Coverage 60° 60°
Frequency response 80 Hz - 20 kHz 70 Hz - 20 kHz
Max SPL at 1mt (peak) 122 dB 123 dB
Amplier Connuous Power 250 W CLASS D with SMPS 250 W CLASS D with SMPS
Input Impedance 30 kohm balanced 15 kohm unbalanced 30 kohm balanced 15 kohm unbalanced
Input Sensivity -10 dBu -10 dBu
Controls LEVEL, PRESET selector (MONITOR, FOH),
GND li
LEVEL, PRESET selector (MONITOR, FOH),
GND li
Connectors IN: COMBO (XLR/JACK) LINK: XLR IN: COMBO (XLR/JACK) LINK: XLR
Power Supply 100-240 V a.c. - 50/60 Hz 100-240 V a.c. - 50/60 Hz
Rated Consumpon* 200 W 200 W
Construcon MDF with black an-scratch polyurethane
paint
MDF with black an-scratch polyurethane
paint
Pole Adapter 1 x side 1 x side
Handles 1 x sides 1 x sides
Monitor taper 36° 36°
Weight 8 kg (17.6 lb) 10 kg (22.0 lb)
Dimensions (W x H x D) 325 x 336 x 233 mm 390 x 396 x 270 mm
* Rated consumpon is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.
TECHNICAL SPECIFICATIONS
ACCESSORIES
FRE300BK
Professional aluminium oor-stand for speaker with terminal pieces Ø 35mm. Supplied with a screw locking system, a
steel safety pin and “Aircushioned” air-damped release device to grant a exible, fast and easy adjustment.
Load capacity: 35Kg
Adjustment: 1350-2150 mm.
FRE300KIT
Pair of FRE300BK aluminium speaker stands, provided with a praccal nylon 210D carrying bag.
FRE180KITV2
Pair of loudspeaker stands, made of steel and nylon parts with addional glass bre, to ensure high reliability and
resistance. Steel legs joint. Scratch-resistant mae black nish. Equipped with height adjustment screw system and steel
safety pin. Supplied with a praccal Nylon210D carrying bag.
Load capacity: 40Kg
Adjustment: 1200-1800 mm
