13
17. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included hex keys in a secure place; the large hex key is used to adjust the walking belt
(see page 26). To protect the floor or carpet, place a mat under the treadmill.
16. Carefully raise the Left Upright (31) and the
Right Upright (not shown).
Remove the knob from the pin. Make sure that
t
he collar and the spring are on the pin as
shown. Insert the pin into the Latch Housing
(30), and tighten the knob back onto the pin.
30
31
16
K
nob
Pin
Collar
Spring
To Next Page
