ProForm 450 Cx Treadmill User Manual

12
14. Slide the Left Base Leg Cover (101) onto the
Base (48) as shown. Attach the Left Base Leg
Cover with three 3/4" Screws (2).
Be careful not
to overtighten the Screws.
2
48
2
2
14
15. Tighten a 3/4" Screw (2) into each side of the
Base (48) and each Base Leg Cover (101, 102).
Be careful not to overtighten the Screws.
2
102
101
48
15
101
13. Attach the ground wire on the Upright Wire (28)
to the indicated hole in the Base (48) with a
S
ilver Ground Screw (27).
P
ress the indicated grommet into the Right
Upright (36).
Slide the Right Base Leg Cover (102) onto the
Base (48) as shown. Attach the Right Base Leg
Cover with three 3/4" Screws (2). Be careful not
to pinch the Upright Wire (28). Do not over-
tighten the Screws.
102
48
28
36
2
2
G
rommet
Ground Wire
2
1
3
27
