REMOVE THIS EXPLODED DRAWING
AND PART LIST FROM THE MANUAL
Save this EXPLODED DRAWING and PART LIST for future reference.
Note: Specifications are subject to change without notice. For information about
ordering replacement parts, see the back cover of the UserÕs Manual.
PART LISTÑModel No. PETL32063 R0298A
Key
No. Qty. Description
1 1 Left Upright
2 1 Frame Cover
3 1 Ground Screw
4 2 Handrail Nut
5 2 Ground Nut
6 8 3/8Ó Lock Nut
7 1 Speed Knob
8 1 Speed Potentiometer
9 1 Console Base
10* 1 Console
11 1 Key/Clip
12 1 Motor Belt
13 1 Receptacle
14 1 Motor Tension Washer
15 1 Star Washer
16 2 Incline Wheel Nut
17 1 Motor Tension Nut
18 1 Motor Hood
19 30 Small Screw
20 1 Motor Pivot Bolt
21 1 Choke
22 3 Incline Bolt
23 1 Frame
24 12 Anchor Screw
25 1 Wire Harness
26 1 Incline Motor Guard
27 8 Cover Clip
28 4 Hood Anchor
29 1 Hole Plug
30 1 Circuit Breaker
31 1 Filter
32 1 Ground Wire
33 1 Left Foot Rail
34* 1 Motor/Pulley/Fly./Fan
35 1 Pulley/Flywheel/Fan
36 1 Motor
37 1 Controller
38 1 Reed Switch Wire
39 1 Magnet
40 1 4Ó Cable Tie
41 1 Incline Motor
42 1 Front Roller Adj. Bolt
43 3 Adjustment Washer
44 1 Right Upright
45 2 Upright Spacer
46 2 Base Wheel Bolt
47 20 Belly Pan Screw
48 1 Belly Pan
49 2 Belt Guide
50 1 Storage Latch
51 2 Storage Latch Spring
Key
No. Qty. Description
52 2 Frame Guide
53 1 Frame Cover
54 2 Wire Harness Grommet
55 2 Upright Pivot Bolt
56 2 Base Wheel
57 7 Base Pad
58 1 Motor Tension Bolt
59 1 Base
60 1 Safety Cover Connector
61 2 Incline Leg Wheel Bolt
62 1 Book Rack
63 4 Upright Screw
64 1 Incline Rod
65 1 Electronic Bracket
66 20 Latch/Frame Screw
67 6 Handrail Washer
68 2 Roller Endcap Nut
69 2 Incline Leg Bolt
70 2 Latch Pad
71 1 Incline Leg
72 2 Incline Leg Wheel
73 2 Rr. Roller Endcap Screw
74 2 Adjustment Bolt
75 12 Screw
76 1 Allen Wrench
77 1 Adhesive Clip
78 1 Rear Roller Endcap
79 1 Rear Roller
80 1 Incline Switch
81 1 Latch Decal
82 1 Battery Cover
83 4 8Ó Cable Tie
84 1 Walking Belt
85 1 Walking Platform
86 8 Platform Screw
87 8 Isolator
88 1 Filter Bracket
89 1 Shock
90 1 Front Roller/Pulley
91 2 Releasable Cable Tie
92 1 Storage Latch Bracket
93 2 Handrail Bolt
94 2 Frame Guide Spacer
95 1 Reed Switch Clamp
96 1 Motor Pivot Sleeve
97 3 Nylon Motor Washer
98 2 Motor Pivot Bushing
99 4 Plastic Standoff
100 2 Power Bracket
101 1 Frame Plug
102 2 Power Bracket Screw
Key
No. Qty. Description
103 2 Power Bracket Nut
104 1 Filter Circuit Board
105 2 15Ó Wire Tie
106 1 Tie Holder
107 1 Right Foot Rail
108 2 Roller Endcap Washer
# 1 4Ó Black Wire, 2 F
# 1 8Ó Blue Wire Harness
# 1 8Ó Black Wire, M/F
# 1 4Ó Green/Yellow Wire
# 1 8Ó White Wire, 2 F
# 1 14Ó White Wire, M/F
# 1 8Ó Black Wire
# 1 Large Decal Sheet
# 1 Small Decal Sheet
# 1 UserÕs Manual
* Includes all parts shown in the box
# These parts are not illustrated
