6
3
55
41
41
45
45
1
13
36
3. While another person holds the Upright (13) in the
position shown, connect the Upper Wire Harness (36)
t
o the Lower Wire Harness (55).
C
arefully pull the excess Upper Wire Harness (36) out
of the top of the Upright (13), and slide the Upright onto
the Frame (1). Be careful to avoid pinching the Wire
Harnesses. Next, attach the Upright with three M8 x
25mm Button Screws (45) and three M8 Split Washers
(41).
Be careful to avoid
pinching the wire
harnesses while
attaching the
upright.
4
4. Attach the Handlebar (15) to the Upright (13) with two
M8 x 38mm Button Screws (9).
13
15
9
