ProForm LX 360 - Part Identification Chart

3/4” Screw (2)–8
1/2” Silver
Screw (49)–3
Wheel Bolt (64)–2
Nut (13)–2
1” Tek Screw (58)–4
3/8” Star Washer (38)–4
5/16” Star Washer (63)–4
Crossbar Screw
(39)–2
2 1/2” Bolt (37)–4
3” Bolt (61)–4
U-Nut (108)–4
Upright Nut (109)–4
1” Latch Screw (110)–2
Remove this chart and use it to identify small parts during assembly. Save
this chart and the EXPLODED DRAWING/PART LIST for future reference.
PART IDENTIFICATION CHART
