4.3 Bar Diameter
Based on the regional setting, the bar diameter
menu supports following bar dimensions.
Metric ASTM Japanese
Bar
size
Diam.
(mm)
Bar
size
Diam.
(inch)
Diam.
(mm)
Bar
size
Diam.
(mm)
5 5 #2 0.250 6 6 6
6 6 #3 0.375 10 9 9
7 7 #4 0.500 13 10 10
8 8 #5 0.625 16 13 13
9 9 #6 0.750 19 16 16
10 10 #7 0.875 22 19 19
11 11 #8 1.000 25 22 22
12 12 #9 1.125 29 25 25
14 14 #10 1.250 32 29 29
16 16 #11 1.375 35 32 32
18 18 #12 1.500 38 35 35
20 20 #13 1.625 41 38 38
22 22 #14 1.750 44 41 41
25 25 #15 1.875 48 44 44
28 28 #16 2.000 51 48 48
32 32 #18 2.250 57 51 51
36 36 57 57
40 40
44 44
50 50
4.4 Measuring Range Selection
Select according to the depth of the rebars. When-
ever possible, choose the short range.
Auto
Automatic switch from short to long if
no signal in short range
Short
< 80 mm < 3 inch
Long
< 180 mm < 7 inch
