ProFusion HA24-75E - EXTERNAL THERMOSTAT INSTALLATION; Installation Steps

The external thermostat installation as below:
1.prize up the hole
2.Screw out the two screws
3.Strip away the cover of wire for 50mm
4.Tightening the wire
5.twisted into a circle
6.
6.
Put in the wires through the hole
Put in the wires through the hole
7.Conected the wires to machine
and make it secured
