17
OVERVIEW TECHNICAL DATA
MECHANICAL PROPERTIES:
Dimensions: ············· 298 x 203 x 25 mm (3.74 x 2.06 x 0.94 in)
Weight: ······················· 840g (26.4 oz)
ELECTRICAL PROPERTIES:
Power supply: ····················· 24 V DC (1.67A)
The 10-Slot Charging Station provides multiple options to mount
to flat surfaces, workstations and racks. The charging status is
indicated by the LEDs of the scanner. The LEDs pulse red while in
charging mode. When the battery is fully charged, the LEDs pulse
green constantly.
10-SLOT CHARGING STATION
MOUNTING
Do not mount the 10-Slot Charging Station higher than 2m!
On the front and back side are different holes and recesses to enable
secure mounting of the 10-Slot Charging Station (with screws and/or
zip-ties). Two wall mount slots on the back side can be used to fix the
device with screw heads 135mm apart from each other. The rail slot
on the back enables mounting to a standard DIN rail, facilitating the
installation in an IT rack or similar constructions. Additionally, the 10-
Slot Charging Station can be installed on a monitor arm or stand with
holes 75mm appart horizontally and vertically.
CAUTION
