CHARGING STATION S
OVERVIEW TECHNICAL DATA
The Charging Station S consists of two charging trays that
charge two scanners at the same time. The charging status
is indicated by the LEDs of the scanner. The LEDs pulse red
while in charging mode. When the battery is fully charged,
the LEDs pulse green constantly. The Charging Station S
can be attached to work stations, for example, through the
attachment openings (with M5 screws or cable ties).
MECHANICAL PROPERTIES:
Dimensions: ·············· 140 x 56 x 19mm (5.5 x 2.2 x 0.7 in)
Weight: ························ 125g (4.4 oz)
ELECTRICAL PROPERTIES:
Power supply: ············ 5 V DC (1.2 A)
Attachment
opening for
M5 screws
Charging
Pins
Charging slot
Product label
Attachment opening
for cable ties
USB-C
NOTE
Further technical specifications are
available on docs.proglove.com
