User Manual | Agrónic 2500
Parameters | Filters
PS Start programs, a digital sensor will begin the ir-
rigation of one or more programs. The input will no
longer be accepted if the programs or their sequences
have not terminated.
AL Alarm, a normally closed digital sensor will send an
SMS when the contact is opened.
GENERAL PARAMETERS
Irrigation meter:
value per pulse: 00100.00 L
Delay without pulse: 010’
Fertilizing meter:
pulse per value: 00001.00 L
Delay without pulse: 010’
Detection delay
Input SC: 030”
Delay, detection
Input TM: 180”
Irrigation meter
The input allows a maximum of 5 pulses per seconds.
Pulse value (00000 ... 90000 L): volume measured by
each pulse.
Delay with no pulse (000 ... 255’): time in minutes that
must transpire without receiving pulses from the meter
for a definitive malfunction to occur and irrigation to
stop (At 0 there is no meter error control).
Fertilizing meter
If the fertilization is in parallel and there are several
meters, they are all are assigned the same values. The
input allows a maximum of 5 pulses per seconds.
Pulse value (00000 ... 90000 L): volume measured by
each pulse.
Delay with no pulse (000 ... 255’): time in minutes that
must transpire without receiving pulses from the
meter to stop fertilization (At 0 there is no meter error
control).
Sensors SC, TM, DM, CS, PS, AL.
Only for sensors that have an input assigned.
Detection delay (000 ... 999”): time in seconds that
the input must be active in order for it to perform the
function.
Outputs
At the base of the Agrónic 2500, there can be up to 27
digital outputs, identified as R1 to R27, to connect the
general outputs. Start with the unit’s last outputs and
reserve the first ones for the sectors.
GENERAL PARAMETERS
Assign outputs:
m1 M2
18 17
Assign outputs:
f1 F2 FG
15 14 16
Assign outputs:
m1 M2 FC
13 12 20
Assign outputs:
c1 C4 GC
10 7 11
Pumps
P1 and P2: outputs connected to pumps or general
valves.
Fertilizers
F1, F2, F3, F4: outputs connected to the fertilizing
injectors.
FG: output connected to the pump or general fertiliz-
ing.
M1, M2, M3, M4: outputs connected to the mixers.
FC: output connected to the fertilizing cleaning valve.
Filter cleaning.
Before assigning the outputs, configure how many
filters there are in the installation. This is assigned in
‘Function - 4. Parameters - 2. Filters’.
C1: output assigned to the first filter.
Cx: output assigned to the last filter.
GC: output connected to the general filter cleaning
valve.
The outputs that occupy the filters between the first
and last are assigned automatically. If there is only one
filter, the last one is not asked.
