User Manual | Agrónic 2500
DIGITAL OUTPUTS
DIGITAL INPUTS
6 INPUT AND OUTPUT CODING
The inputs and outputs are coded in a way that makes it easy to indicate where they are located;
There are five digits in total. The most significant indicates the unit: base, AgroBee or AgroBee-L,
the next two digits for the AgroBee, AgroBee-L module number or internal values and the last
two for the input or output number.
0: base 00 01 - 27 Base output
1: agroBee 01 - 16 01 - 09 Depends on the AgroBee model
3: agroBee-L 01 - 20 01 - 09 Depends on the AgroBee-L model
0 00 00 Description
0 00 00 Description
0: base
00 01 - 12 01 to 10: base
01 01 - 02
01: voltage on the outputs
02: voltage on the solar panel
The sections on Programming,
Manual Actions and
Query are detailed in the
User Manual
r2467 r2469
Example
30102: output 2 of the module 1 of the AgroBee-L system
See User Manual
