User Manual | Agrónic 2500
Parameters | Filters
The Agrónic can control the filter cleaning. Cleaning
can be started manually or automatically.
It starts automatically by a dierential pressure gage
or by an amount of time or a volume of water having
passed through the filters. It will only start automati-
cally if the general one (P1 or P2) assigned to the filters
is activated. In other words, when there is a program
irrigating. It can be started manually whenever desired
from ‘Function - 2. Manual - 4. Filters’.
FILTER PARAMETERS
N. of filters: 5
Initial wait: 000”
Time of activation
by filter: 045”
Pause between filters: 04”
Units between cleanings
Volume: 0000 m3
Time: 0000 ‘
General filter: no
Relationship with P1: yes
Relationship with P2: no
Max. number of continuous
cleanings: 0
Sector stop: no
Number of filters (0 ... 9): number of filters.
Initial wait (000 ... 999”): the waiting time between ac-
tivating the filter general and starting cleaning the first
filter.
5.2. FILTERS
Time of activation by filter (000 ... 999”): time that the
water will pass through each filter to perform cleaning.
Pause between filters (00 ... 99”): waiting time between
closing the cleaning of one filter and activating the
next one.
Units between cleanings (0000 ... 9999): the irrigation
time or volume that must pass through the filters for
automatic cleaning to begin. Time in minutes and
volume in m3.
General of filters (No | Yes): indicate ‘Yes’ to activate an
output during the entire filter washing process.
Relation with P1, P2 (No | Yes): it indicates the pump
from which the water that passes through the filters
comes from. It is used to count units between cleanings
and to run the cleaning.
Maximum number of consecutive cleanings (0 ... 9): if
cleaning is started by the dierential pressure gage
and is always activated, it will do the cleanings config-
ured here at most. It then goes into malfunction and
will not continue cleanings until it is manually recon-
figured. At 0, it never goes into malfunction.
To restart cleaning go to ‘Function - 2. Manual - 4.
Filters’.
Stop of sectors (No | Yes): if cleaning takes place during
irrigation, select whether or not to postpone the irriga-
tion while it does so. It is used when sectors must be
closed during cleaning to maintain pressure.
• Yes: programs that have sectors related to the
pump that use cleaning are postponed. When the
cleaning is finished, the programs continue where
they were.
• No: the programs remain active during cleaning
and the irrigation sectors are not closed.
Video tutorial
available for
this section
before the program starts. If it is less than 10 minutes since
the last irrigation, do not run the pre-mixing.
Mixing during fertilization can be continuous or with
pauses.
Mixing start (000 ... 999”): mixing time before a pause. If con-
tinuous mixing is desired, set the mixing pause to 0 and any
time here.
Mixing stop (000 ... 999”): time that the mixing will be
stopped aer a running time. If continuous mixing is
desired, set this time to 0.
Last cleaning (000 ... 999”): when fertilization ends, the
general and fertilizing cleaning outputs are activated
during this time. If the fertilization is in series, it cleans at
the termination of each fertilizing. If it is in parallel, when
the last one ends.
