ProLights MOBY40 - Appendice; Vista Esplosa

MOBY40
28
- 5 - APPENDICE
5.1 VISTA ESPLOSA
No ITEM
1 Take indicator light waterproof button switch
2 Diode socket
3 Three color LED
4 Clear glass
5
Lens waterproof rubber ring
6
Ø 80 lens
7
LED board
8
Copper water joint
9
Lithium battery components
10
Wireless receiver PCB
11
Driver board
12
Isolation sheet
13
Control board
14
Display board
15
Line board base
16
Adaptor PCB
17
Waterproof button switch
18
Power connector reds (male)
19
Display screen lens
20
Rubber foot
21
Waterproof power switch
22
Watertight strain relief
23
Infrared receiving head
24
Waterproof antenna
25
10° frosted akes
26
Rubber cover
