ProLights MOBY40 - Page 35

5
MOBY40
Structure and Power supply
• Protection: IP44, IP54 (with rain-cover)
• Steel cover with mirror nishing
• Internal Protection: IP44 (indoor/outdoor)
• Tempered glass front panel
• Battery: 24V
• Battery autonomy: 24 hours (color change mode), 12 hours (permanent white full-on)
• Recharge operations: 6-units Road case with integrated battery charger or by external power supply
• Recharge time: 12 hours max
• LED battery status indicator
• Load/Storage battery switch
• Dmx connections: XLR 3p Input/Output
• Ergonomic carrying handle for transportation and positioning
• Adjustable foot support for tilt regulation (up to 10°)
• Power unit: 100-240V 50/60Hz
• Working temperature: 0/+35°
• Weight: 5,5 kg
• Dimensions (WxHxD): 154x287x154 mm
Photometric data
Fig.1
Fig.2
154
154 287
Illuminance at a Distance
13°
2.0m
0m
4.0m
6.0m
8.0m
10.0m
0.45m
0.91m
1.36m
1.82m
Lux Center Beam Angle: 13° Beam Width
1997lx
499lx
221lx
124lx
2.27m79lx
