PROLYNX PL-510 - Transmitter Specifications; Receiver Specifications

Transmitter
RF Power
≤5W(High) / 1W(Low)
Frequency Stability
<1.5ppm
Spurious & Harmonics
-36dBm<1GHz,
-30dBm>1GHz
FM Hum & Noise
65dB(Wide) / 55dB(Narrow)
Modulation Deviation
≤5kHz(Wide) / ≤2.5kHz(Narrow)
Adjacent Channel Power
70dBC(Wide) / 60dBC(Narrow)
Audio Frequency Response
+1 ~ -3dB
Audio Distortion
<3%
Receiver
Sensitivity (12 dB SINAD)
0.25μV(Wide) / 0.35μV(Narrow)
Adjacent Channel Selectivity
70dBC(Wide) / 60dBC(Narrow)
Audio Distortion
< 5%
Radiated Spurious Emissions
< -54dBm
Intermodulation Rejection
60dB
Audio Output
1000mW @ 16 ohms
Hereby, we declare that our radio is in compliance with the essential
requirement and other relevant provisions of Directive.
