USER’S MANUAL. PROMAX-25
Page 28 09/2004
4.3 Connection to a Computer or Printer.
The PROMAX-25 permits the connection to a PC or to a serial printer for data
transfer, by means of the connection cable model CC-208.
Do not connect any cable other than that supplied by the manufacturer,
otherwise serious damage may be caused to the equipment.
1) Prior to connecting the equipment to a PC, disconnect both from their
respective power supplies.
2) Connect the end of the connection cable corresponding to the PROMAX-25 to
connection [8] and the other end to the serial port of your computer or printer.
Once the computer or printer have been connected, select on the PROMAX-25
the LOGGER operation mode. If PRINT function is selected data will be dumped to the
remote unit through the serial port.
The communication parameters used by the PROMAX-25, and which therefore
must be defined on the remote unit (PC ) are the following:
Rate 57600 bauds
Data bits 8 bits
Parity None
Stop bits 1
The remote control software RM-025 (optional accessory) permits to carry out
from a computer the following options:
1) CHANNELS PLAN PROCESSOR: Modify, add or delete channel plans.
2) DATALOGGER: Permits to edit and to save all the measurement contained in a
logger.
3) UPGRADE: Allows to update the PROMAX-25 software version.
