30 ActivPanel User Guide
With your screen cursor positioned over an empty area of the control panel, press down on the
pen display screen with your pen’s eraser to test the current eraser feel setting. Use the Current
Pressure bar to determine how hard you must press on the eraser to reach maximum pressure.
Adjusting Eraser Feel
To adjust the eraser sensitivity of your pen, select the Eraser tab.
Note:
Some product configurations may include a pen without an eraser.
Advanced Tip and Eraser Pressure Settings
To further customize tip or eraser pressure settings, select the pen or eraser tab and click on the Details...
button. The options within the feel details dialog box enable you to change the tip or eraser pressure
sensitivity and click threshold settings independently. (In the pen and eraser tabs, these settings are
adjusted simultaneously with the tip feel or eraser feel slider.)
Displays the eraser Feel
Details dialog box where
you can further customize
the eraser sensitivity.
Customizes the amount of
pressure needed to erase.
Select the button
function to perform when
using the eraser.
Drag the slider to select a pressure sensitivity setting. If you
have a soft touch and want to achieve full pressure without
having to apply full force to your pen, choose a softer setting.
The Profile graphically displays the selected pressure
Sensitivity curve and Click Threshold settings. A curve
that increases quickly makes the pen feel more sensitive.
Drag the slider to adjust the click threshold level. This setting
determines the amount of force required to generate a tip click.
Using your pen tip or eraser, make several strokes within
the box to test the results of your changes.
