1 Identity code
Product range CONCEPT plus, Version b
CNP
b
Type
_ _ _
_
Performance data at maximum back pressure and type: refer to nameplate on the
pump housing
Material
PP Polypropylene
NP Clear acrylic/PVC
PV PVDF
Diaphragm and seal
E Standard with EPDM seals
B Standard with FPM seals
T Standard with PTFE flat seal
Dosing head design
0 Without bleed valve, without valve spring
1 Without bleed valve, with valve spring
2 With bleed valve, without valve spring
3 With bleed valve, with valve spring
Hydraulic connector
0 Standard connection
Design
0 with ProMinent logo
Electrical connections
A 100 - 230 V, standard European plug
B 100 - 230 V, Swiss plug
C 100 - 230 V, Australian plug
D 100 - 230 V, USA plug
Cable assembly
Identity code
4
